VPC 160 screw pump

(40 bar and 70 bar)

Applications:

  • High pressure pumps with low volumetric delivery
  • Cutting, turning milling, boring, grinding and similar applications of machine tools
  • Especially used for deep hole boring operations due to the high pressure up to 100 bar
  • Pumping cutting/cooling fluids in circulation systems

Fluid Specifications:

  • Coolants
  • Cutting oils
  • Grinding oil
  • Emulsions (minimum 5% oil)
  • Thermal oils (contact for detailed information)
  • Kinematic viscosity 1…400 mm2 /s (contact for higher viscosities)

Materials:

Spindles: high performance steel, hardened steel

Pump body: Cast iron – DIN GG 26, specially heat treated

Discharge casing: Cast iron – DIN GG 26

Housing: Aluminium

Mechanical seal: SiC-SiC-Viton

O-ring: Viton

suction pipe: Steel

Motor:

IE2 3-phase induction motor

2-pole, 2900 RPM

Protection degree, IP 55

Insulation class F

NOTE! The used fluid must be filtered through at least a 50 micron filter

TypeOutput
(kW)
Current
(A)
Voltage 3-phase
(V)
Weight
(kg)
Discharge
volume
1 cSt
(l/min)
Discharge
volume
20 cSt
(l/min)
Cable entry
40 bar412,6/ 7,25200/40046,539,641,61,5 x M20
70 bar7,513,24007434,540,21,5 x M25
TypeDimension a
(mm)
Dimension b
(mm)
Dimension c
(mm)
40 bar218580157
70 bar258705198
VPC160 dimensions
PERFORMANCE CURVE
