Evotech

The revolutionary EVOTECH bed coolant filters utilize innovative principles of operation and exclusive design concepts to provide the very highest level of performance.

Evotech (Brochure)

Working principle

The contaminated liquid (2) is conveyed to the filter accumulation area, creating a basin where the liquid passes through the filter fabric by gravity (6). The polluting particles are separated and deposited on the filter media (3), improving filtration efficiency.
When the fabric is clogged, a float activates a switch (4) that signals total filter clogging. This starts the gear motor to drive the filter fabric (5), replacing the exhausted portion of fabric with clean fabric (1). The exhausted fabric is scraped and rewound (7), facilitating waste separation and reducing maintenance time and disposal costs.

	EVO 300	EVO 500	EVO 700	EVO 1000	EVO 1200	EVO 1500
Tank capacity (l)	135	240	465	610	770	1150
Emulsio flow rate (l/min)	40	80	140	220	280	350
Oil flow rate (l/min)	20	40	70	110	140	175
Pressure (bar)	0,2	0,2	0,2	0,2	0,2	0,2
Pump power (kW)	0,16	0,30	0,40	0,53	1,15	1,47
Motor power (kW)	0,12	0,12	0,12	0,12	0,12	0,12
Weight (kg)	71	114	163	197	237	302

	EVO 300	EVO 500	EVO 700	EVO 1000	EVO 1200	EVO 1500
A	760	960	1250	1620	2050	2000
B	700	1000	1500	1500	1500	1500
C	250	250	250	250	250	350
D	450	450	450	450	450	550
E	300	500	700	1000	1200	1500
F	360	560	760	1060	1260	1560
G	510	510	510	510	510	610
G1	670	670	670	670	670	770
G2	600	600	600	600	600	700
H	260	460	660	860	1160	1460
L	480	730	880	1030	1080	1210
M	450	650	850	1150	1350	1650
N	310	310	310	310	310	310
P	100	100	100	100	100	100
Q	350	350	350	350	350	350
R	580	780	980	1280	1480	1780
S	1010	1310	1810	1810	1810	1810
T	960	1210	1360	1510	1560	1690
V	700	950	1100	1250	1300	1430
